Home / Products / Curtain Motor / ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor

custom ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor

  • ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor

    Electronic limit+Built-in receiver+Resistance and stop function+Light touch-start function+ Power off-manual function+long life time function+External connecting with dry contact function+The Third Four.Four limit position+elegant operation function
    ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor
    • ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor
    • ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor
    • ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio Curtain Motor

    Applications

    lnner Structure Picture

    CONTROL SYSTEM

ID82AE-RS485 Communication function+Built-in Adapter Electronic Radio    Product Certificate
Motor Type Safety Curtain Weight Rated Torque Rated Speed Open/Close Speed Rated Current Running Time Protection Degree Max Number of Turns Track Lenght Weight
Kg N.m rpm cm/s A h IP Turn m kg
100-240V/50Hz.60Hz
ID82AE-RS485-3/28 50 1.2 75 12 0.13 240 40 ≤12 1.04

Motorized Curtain Function Description:

  • Elegant Operation Function

    DC curtain motor with light open and light close function. When it starts and nears the limit position.The speed will obviously slow and make the curtain running more elegantly.

  • Electronic Memory Limit Function

    This motor with electronic limit, no need to set the limit position by hand, it greatly shortens the debugging time. The electronic limit function can automatically delete the limit difference of each day and keep the precise limit position for a long time.

  • Built-in Receiver Function

    FEERGE curtain motor is endowed with built-in receiver function, which is compatible with any other type of FElERGE emitters. Curtains can be controlled separately or in a group system.

  • Resistance And Stop Function

    The curtain will automatically stop if meet resistance.

  • Light Touch-Start Function

    If use hand to pull the curtain lightly around 20CM, the curtain will run automatically and stop until fully opened or fully closed (no need use remote).

  • Long Lifetime,Durable In Use

    Use high strength synchronous belt with anti-aging and acid-resistance function, This system can keep its shape after 15,000 times' use, lt has 20 years' life span if calculated by 2 time per day.

  • Power of Manual Function

    When the power is off, just do as we do to a common manua operated curtain, we can lightly pull the curtain to open and close.

  • External dry contact switch function

    Through the dry contact, can connect the mechanical switch or light-touch switch.
